P0500 board-in series
Pitch: 0.5mm
Features
Circuits: 67P
Current: 0.5A
Type：M(5+4)&B(6+5)
Application: Notebook、Tablet
1.2K/Reel
M.2的主要應用終端：
平板電腦
智能電視
超級本
GPS裝置
服務器
固態硬盤
游戲機
M.2 Key典型應用：
A Key：主要應用于無線連接，如WiFi，藍牙，NFC，Wigig?？ǖ念愋桶?630，2230和3030。
B Key：主要應用于WWAN，GNSS，SSD。卡的類型包括3042，2230，2242，2260，2280和22110。
E Key：主要應用于無線連接，如WiFi，藍牙，NFC，GNSS?？ǖ念愋桶?630，2230和3030。
M Key：主要應用于支持PCIe或SATA協議的主機界面，通常為SSD。
特別的：M.2的連接器共有三種Socket（Socket1、2、3），因Socket1全部采用焊接方式且僅適用于1216，2226和3026尺寸，
故常見M.2設備連接器多為Socket2和Socket3兩種。
————————————————
版權聲明：本文為CSDN博主「Spuer_IO」的原創文章，遵循 CC 4.0 BY-SA 版權協議，轉載請附上原文出處鏈接及本聲明。
原文鏈接：https://blog.csdn.net/spuer_io/article/details/54981079
帶有 67 個位置的 0.5mm 間距
適用于單面和雙面模塊
提供針對模塊卡的多種鍵控選項
支持 PCI Express 3.0、USB 3.0 和 SATA 3.0
高度、位置、設計和鍵控方面的選擇
有多種高度可選
